HFSS15: User Defined Model (UDM) for ANSYS WB Integration
A User Defined Model (UDM) is collection of externally defined parts imported into an ANSYS EM 3D Modeler.
UDM includes part attributes (like name, color etc) and material assignment
UDM can also have external coordinate systems and corresponding planes
UDM parts can be parameterized and manipulated in ANSYS EM modeler just like any other part
UDM can either represent Static geometry models or
Dynamic links to models of external geometry editors
Used for supporting CAD integration in WorkBench
UDM uses same plugin technology as User Defined Part (UDP)
See the following sections:
UDM compared to User Defined Primitives
Insert UDM Command on Draw Menu
UDM Properties
Library of Models for CAD Integration
ANSYS EM to ANSYS Geometry Transfer
Material Assignment Transfer
Geometry Transfer through ANSYS DesignModeler (DM)
